QSC touchmix-30 pro User Manual

67
1001108-01-F
S G − S
(TM- P )
Rename the Sub Channel, assign Input channels to the
group, and assign/unassign the group to the Main L/R.
1. Setup tab – Selects the Sub Group Setup
screen.
2. Name – Touch the Name to display a
keyboard that may be used to enter a name for
the channel.
3. Link – Touch the Link button to link the
channel with the adjacent channel. Always links
odd to even.
4. Reset – Returns settings to the factory
default.
5. No/Yes – Select “Yes” to automatically
unassign an input channel from the Main L/R
when it is assigned to the Sub Group.
6. Input Channel numbering, both system (1) and
user assigned (In 1).
7.
L/R assigned
L/R
– Indicates the Sub
Group is assigned to the Main L/R outputs.
8.
L/R unassigned
L/R
– Indicates the
Sub Group is not assigned to the Main L/R
outputs.
9. Main L/R assignment button – Assigns and unassigns this Sub Group to the Main L/R outputs.
Press Menu
Touch FX
Masters
Touch an
FX Channel
Touch
Setup
Sub 1
Inputs 1-8
Sub Groups
Setup
1
2 3 4
5
6
8
9
7

QSC touchmix-30 pro Specifications

General

Type	Digital Mixer
Channels	32
USB Interface	Yes
Effects Processors	4
Wireless Control	Yes
Phantom Power	Yes
Outputs - Aux	6
EQ Bands	4-band parametric
Computer Connectivity	USB
A/D Resolution	24-bit
Sampling Rate	48kHz
Bit Depth	24-bit
Wireless Control Platforms	iOS, Android
Aux Outputs	6
Main Outputs	2
Touchscreen	Yes
Headphones	1
Effects	Reverb, Delay, Chorus
USB	2.0
Power Source	AC
Display	10-inch Touchscreen
Stereo Line Inputs	2 stereo pairs
Inputs - Line	2 stereo pairs
