33
1001108-01-F
TM- P S
Parameter Specification
Display 10” (254mm) diagonal, 1024 x 600 pixel, color TFT, capacitive multi-touch sensing
Inputs Total 32
20 Mic/Line, XLR, 48V Phantom Power
4 Mic/Line, XLR/TRS combo, 48V Phantom Power
6 Line (1/4” TRS + 1/8” (3.5 mm) TRS top panel)
USB MP3 Playback (Type A rear panel)
1 Talkback (XLR with 48 V)
Outputs 22 Total
2 Main L/R (XLR)
14 Aux Outputs (XLR)
2 In-ear Monitor (Stereo) (1/4” TRS from Auxes 11/12 and 13/14)
1 Cue (Stereo) (1/4” TRS)
2 Monitor (Stereo) (XLR)
Digital Connections 2 USB A connector,
1 USB B connector,
1 RJ-45 (connection for Wi-Fi router)
Input Channel Processing 4-band Parametric EQ with Hi/Low Shelving Option
Variable 24 dB/octave HPF and LPF
Gate
Compressor
Delay (100 msec max)
Effects (FX) 6 FX Engines
Reverb
Echo
Delay
Chorus
Pitch Shift (assignable to a single mono input channel)
Output Channel Processing 1/3 Octave Graphic EQ (Main L/R, Aux 1 - 14 )
Parametric EQ (Main L/R, Aux 1 - 14)
Notch Filters (12-bands, all outputs)
100 msec. Delay, (all outputs)
Limiter (all outputs)
HPF & LPF (all outputs)
Sub Group Processing 6-band PEQ
HPF, LPF
Compressor / Limiter
Recording/Playback USB Direct to Hard Drive multi-track (32 x 32)
DAW / Computer interface 32 x 32 channel USB audio interface to Windows and macOS computers.
Stereo MP3 Playback from USB
Groups 8 DCA
8 Mute
8 Sub Groups
Cue Selectable
AFL
PFL
Solo in Place
Real Time Analyzer 2 x 1/3 octave
1 assigned to the selected channel
1 with user selectable source
Wizards Anti-Feedback, Room Tuning, Gain, Effects
