QSC touchmix-30 pro User Manual

132
1001108-01-F
Main Outputs
L R
Cue
L R
Aux (Odd)
To Multi-Track
FX Sub-Groups (odd) * Sub-Groups (even) * Aux (Even)
Meter
Ch Fader
Pre
Post
From DCA Masters
Post Fdr
Pre Fdr
Pre Dyn
Pre all
Pre
Post
Mute
Logic
FX Send
Aux Send (Stereo)
RTA
Assign
Post Fdr
Pre Fdr
Pre Dyn
Pre all
Aux Send (Mono)
* TouchMix-30 only
PEQ
Limiter Low Cut High Cut
Gain
Gain Mute
Pan
Mute
Mute
Mute
Pan
Cue
Mono Sub Group (TouchMix-30 only)

QSC touchmix-30 pro Specifications

General

Type	Digital Mixer
Channels	32
USB Interface	Yes
Effects Processors	4
Wireless Control	Yes
Phantom Power	Yes
Outputs - Aux	6
EQ Bands	4-band parametric
Computer Connectivity	USB
A/D Resolution	24-bit
Sampling Rate	48kHz
Bit Depth	24-bit
Wireless Control Platforms	iOS, Android
Aux Outputs	6
Main Outputs	2
Touchscreen	Yes
Headphones	1
Effects	Reverb, Delay, Chorus
USB	2.0
Power Source	AC
Display	10-inch Touchscreen
Stereo Line Inputs	2 stereo pairs
Inputs - Line	2 stereo pairs
