QSC touchmix-30 pro User Manual

134
1001108-01-F
Main Outputs
L R
Cue
L R
Aux (Odd)
To Multi-Track
FX Sub-Groups (odd) * Sub-Groups (even) * Aux (Even)
Meter
Ch Fader
Pre
Post
From DCA Masters
Mute
Logic
* TouchMix-30 only
RTA
Assign
SUM
Lush Reverb
Dense Reverb
Pitch Shift
Chorus
Mono Delay
Stereo Delay
Mute
Cue
Aux Send (Stereo)
Mute
Balance
Balance
Gain
Gain
PEQ
Low Cut
SUM
Aux Send (Mono, Odd Auxes)
Mute
SUM
Aux Send (Mono, Even Auxes)
Mute
FX Return

QSC touchmix-30 pro Specifications

General

Type	Digital Mixer
Channels	32
USB Interface	Yes
Effects Processors	4
Wireless Control	Yes
Phantom Power	Yes
Outputs - Aux	6
EQ Bands	4-band parametric
Computer Connectivity	USB
A/D Resolution	24-bit
Sampling Rate	48kHz
Bit Depth	24-bit
Wireless Control Platforms	iOS, Android
Aux Outputs	6
Main Outputs	2
Touchscreen	Yes
Headphones	1
Effects	Reverb, Delay, Chorus
USB	2.0
Power Source	AC
Display	10-inch Touchscreen
Stereo Line Inputs	2 stereo pairs
Inputs - Line	2 stereo pairs
