35
1001108-01-F
TM- TM- S
TouchMix-8 TouchMix-16
Display 6.1” x 3.5” (156mm x 90mm) color TFT, touch sensing.
Inputs (Mic/Line)
1
Total 12
4 XLR / TRS combo (48V Phantom Pwr)
4 XLR (48V Phantom Pwr)
2 Stereo, TRS
Total 18
4 XLR / TRS combo (48V Phantom Pwr)
12 XLR (48V Phantom Pwr)
2 Stereo TRS
Input (Talkback) N/A 1 XLR
Outputs
1
Total 8
2 Main, XLR, line-level
4 Auxes, XLR, line-level
1 Stereo TRS Cue/Mon
(Line or headphone, 16 Ω min.imp)
1 Stereo TRS, Aux 3/4
(Line / In-Ear Monitor, 16 Ω min.imp)
Total 12
2 Main, XLR, line-level
6 Auxes, XLR, line-level
2 Stereo auxes, TRS
(Line / In-Ear Monitor, 16 Ω min.imp)
1 Stereo Mon, TRS
(Line or headphone, 16 Ω min.imp)
1 Stereo Cue, TRS
(Line or headphone, 16 Ω min.impedance)
Digital Connections 2 USB type A connectors
Input Channel Processing 4-band parametric EQ with Hi/Low shelving option
Variable 24db/octave Low-cut & High-cut filters
Compressor
Gate
Effects 4 Professional effects engines configurable as:
Reverb (2 types)
Pitch shift
Mono delay
Stereo delay
Chorus.
Pitch Correct (One assignable to any mono input channel)
2-Trk (USB) & FX Return Processing 2-band shelving EQ
Variable 24db/octave Low-cut
Compressor
Gate
Output Channel Processing Main L/R & Aux 1 - 4
1/3 Octave Graphic EQ (GEQ)
Notch Filters (8-bands)
All outputs
6-band Parametric EQ (PEQ)
Variable 18dB/oct Low-cut and High-cut filters
Limiter/Compressor
100 msec. Delay
Main L/R & Aux 1–6:
1/3 octave graphic EQ (GEQ)
Notch Filters (8-bands)
All Outputs
6-band parametric EQ (PEQ)
Variable 18dB/oct Low-cut and High-cut filters
Limiter/Compressor
100 msec. Delay
Recording/Playback
2
USB Direct to Hard Drive multi-track (14 x 14)
Stereo MP3 Playback from USB
USB Direct to Hard Drive multi-track (22 x 22)
Stereo MP3 Playback from USB
Groups 8 DCA groups (with mutes)
8 Mute groups
Cue Selectable AFL or PFL
Real Time Analyzer 1 x 1/3 octave
Scene and Preset Memory 100 User Scenes
100 User Presets
100 FX presets
