QSC touchmix-30 pro User Manual

64
1001108-01-F
S G − FX S
(TM- P )
Controls how much of the Sub Group audio is sent to
the FX devices.
1. FX tab – Selects the FX Sends screen.
2. FX Overview button – Navigates to the
FX Overview screen for a view of all 6 FX sends from
allinputs.
3. Simple – Hides the Global FX Parameters for
a simpler setup.
4. Reset – Resets the FX sliders, Pre/Post
settings, and the Pitch Correct settings. This
button does not reset the settings for the FX
processors including the Global FX Parameters
on this screen.
5. FX Buses – The icon indicates what
processor has been selected for an FX mix.
Touch the icon to navigate to the processor.
6. FX Label – The larger text identifies the FX bus
1 – 6, and does not change. The smaller text can
be changed in the FX processor Setup screen.
7. FX Send sliders – Sets the level of audio “sent”
from the channel to the FX mix; “-inf” is off. The
digital read-out to the right of the slider indicates
the slidersetting.
8. Global FX Parameters – Provides
control over the two most important parameters of the selected FX device. The controls are different depending on the selected
processor.
9. Pre/Post fader – Selects a pre-fader or post-fader (default) pick-off point for the FX send. Changing this setting will change the pick-
off for allinputs.
Home
Touch Sub
Groups
Bank
Touch
Channel
Touch
FX Tab
Main Mix
L/R
Joe’s Monitor
Aux 1
Aux 2
Aux 2
Aux 3
Aux 3
Aux 4
Aux 4
Aux 5
Aux 5
Aux 6
Aux 6
Aux 7
Aux 7
Aux 8
Aux 8
Aux 9
Aux 9
Aux 10
Aux 10
Aux 11
Aux 11
Aux 12
Aux 12
Aux 13
Aux 13
Aux 14
Aux 14
FX Overview Auxes Setup EQ PresetsComp
Prev
Next
L
48
L
F
LR
1 2
3 4
5 6
7 8
∞
∞
Cue
L C R
Sub
1
10
5
u
5
10
20
0
40
10
10
5
u
5
10
20
0
40
10
Sub 1 Main
Cue
Main
L/R
Mute Mute
Default
Scene:
FX 1
FX 2
FX 3
FX 4
FX 5
FX 6
Joe’s FX
FX 2
FX 3
FX 4
FX 5
FX 6
FX Buses
Global FX Parameters
Pre/Post
Fader
-40
-20 -10
10
U
-40
-20 -10
10
U
-40
-20 -10
10
U
-40
-20 -10
10
U
-40
-20 -10
10
U
-40
-20 -10
10
U
Key
Blend
Amount
Dry
Wet
Correct
Rate
Slow Fast
Rate Depth
Hz
Rev Time Initial Delay
Sec
mSec
Size Pre Delay
m
mSec
Delay Regen
mSec
%
Param 1 Param 2
Rate Depth
Hz
Dense Reverb
Lush Reverb
Mono Delay
None
Basic Chorus
Chorus
-11.5
-23.0
-inf
-inf
-inf
-inf
2.3
34.0
1.43
1.7
32
1.5
0.63
0.00
0.5
0.5
0.00
0.5 Pre
Pre
Pre
Pre
Post
Pre
E 20% 8.3
SimpleFX Overview Reset
Sub 1
FX
Inputs 1-8
Sub Groups
2 3
1
6
88
5
7
9
4
C

QSC touchmix-30 pro Specifications

General

Type	Digital Mixer
Channels	32
USB Interface	Yes
Effects Processors	4
Wireless Control	Yes
Phantom Power	Yes
Outputs - Aux	6
EQ Bands	4-band parametric
Computer Connectivity	USB
A/D Resolution	24-bit
Sampling Rate	48kHz
Bit Depth	24-bit
Wireless Control Platforms	iOS, Android
Aux Outputs	6
Main Outputs	2
Touchscreen	Yes
Headphones	1
Effects	Reverb, Delay, Chorus
USB	2.0
Power Source	AC
Display	10-inch Touchscreen
Stereo Line Inputs	2 stereo pairs
Inputs - Line	2 stereo pairs
