Quantum DXi4700 User Manual

Chapter 9: Configuration
OST Configuration
Quantum DXi4700 User’s Guide 252
1. Select the mapped IP address and click Edit.
The Edit Target Data IP Mapping window displays (see Figure 157 below).
Figure 157: Edit Target Data IP Mapping
2. In the Target Replication IP box, enter the replication IP address to map the data IP address to.
Note: If you are editing a mapped IP address, you cannot change the target data IP address.
3. Click Apply.
Deleting a Mapped IP Address
Delete a mapped IP address if traffic sent to the target data IP address no longer needs to be routed to a
replication IP address
To delete a mapped IP address, select the IP address and click Delete.
Note: You can select multiple mapped IP addresses to delete at once.
DXi Accent
Use the Accent page to enable or disable Accent. Quantum’s Accent software accelerates backups and
reduces network bandwidth requirements by distributing deduplication between the backup server and the
DXi. OST data sent from the media server to the DXi4700 can be encrypted using AES (Advanced
Encryption Standard) encryption methods.
To access the Accent page, on the OST page, click the Accent tab (see Figure 158 below).
Figure 158: Accent Page
