Quantum DXi4700 User Manual

Chapter 10: Utilities
Analyzer
Quantum DXi4700 User’s Guide 344
Caution: If a healthcheck fails when it is run, there may be a problem in the blockpool that could cause
replication or restore operations to fail. Contact Quantum customer support if a healthcheck fails.
Analyzer
The Analyzer page allows you to analyze the network and disk performance of the DXi4700.
To access the Analyzer page, click the Utilities menu, and then click the Analyzer tab.
The Analyzer page contains the following tabs:
l Network Analyzer below
l Disk Analyzer on page 346
Network Analyzer
The Network Analyzer page allows you to analyze network performance by measuring network
throughput between the DXi4700 and another system (such as another DXi system).
To access the Network Analyzer page, on the Analyzer page, click the Network tab.
The Network Analyzer page contains the following tabs:
l Performance below
l Settings on the next page
Performance
The Performance page allows you to perform network analysis with another system (the target). You can
also view results from the most recently run test
To access the Performance page, on the Network Analyzer page, click the Performance tab (see Figure
226 on the next page).
