57
4. Connecting the Printer
Network Connection
Follow the procedure below to connect the printer to the computer through the
network. Prepare the hub and other network devices before connecting the 10
BASE-T or 100 BASE-TX cable to the machine's Ethernet port.
Important
❒ Use shielded Ethernet cable. Unshielded cables create electromagnetic inter-
ference that could cause malfunctions.
❒ Ethernet cable is not supplied with this machine. Select your cable according
to the network environment.
A The network interface cable loop should be about 15 cm (5.9 inches)( )
from the end of the cable (on the end closest to the printer).
B Connect the Ethernet cable to the Ethernet port.
C Connect the other end of the cable to the printer's network, such as a hub.
Reference
For details about network environment settings, see Software Guide.
ZKEP320E
AGN013S
KirP4GB_Setup-F4_FM_forPaper.book Page 57 Wednesday, December 8, 2004 6:05 AM
