Building Technologies Division User Manual LMS14... CC1U7471en
6 The settings in detail 07.05.2014
6.3 Time programs
For the heating circuits and DHW heating, a number of switching programs are
available. They are activated in Automatic operation and control the change of the
temperature levels (including the associated setpoints) via the selected switching times.
During occupancy periods, the Comfort level is maintained, outside the occupancy
periods the Reduced level. Switching programs are only active in Automatic operation.
Available is a 7-day program with a maximum of 3 occupancy periods per day (6
switching points).
The switching times can be set in a combined way, that is, either jointly for several days
or as separate times for individual days. When preselecting groups of days like for
instance Mo…Fr and Sa…Su that use the same switching times, the setting of
switching programs is simplified.
6.3.1 Switching points
Line no. Operating line
HC1 HC2 3/HC3 4/DHW 5
500 520 540 560 600 Preselection
Mo - Su
Mo - Fr
Sa - Su
Mo…Su
Line no. Operating line
HC1 HC2 3/HC3 4/DHW 5
501 521 541 561 601 1st phase on
503 523 543 563 603 2nd phase on
505 525 545 565 605 3rd phase on
Line no. Operating line
HC1 HC2 3/HC3 4/DHW 5
502 522 542 562 602 1st phase off
504 524 544 564 604 2nd phase off
506 526 546 566 606 3rd phase off
Note!
When using function Optimum start/stop control, the effective switching times can
differ from the programmed switching times, the reason being the optimization
process.
6.3.2 Standard program
Line no. Operating line
516, 536, 556, 576,
616
Default values
No
Yes
All time programs can be reset to their default settings. Each time program has its own
operating line to make the reset.
Note!
In that case, individual settings will be lost!
Entering the switching
times
Preselection
Phase on
Phase off
Default values
