595/617
Building Technologies Division User Manual LMS14… CC1U7471en
8 Technical data 28.01.2015
8.2 Parameter stick AGU2.56xx109
Degree of protection IP20
Safety class Safety class III
Degree of contamination 2
Dimensions 60x20x12 mm (LxWxH)
Weight Approx. 16 g
Mounting position Optional
Life cycle Max. 300 h
Electrical data Mains supply DC 5 V ±5%
Warning!
Use parameter stick only for setting the parameters on the LMS14...
Do not plug it in during operation and do not use it for continuous operation!
Storage DIN EN 60721-3-1
- Climatic conditions Class 1K3
- Mechanical conditions Class 1M3
- Temperature range -20...60 °C
- Humidity <90% r.h. (noncondensing)
Transport DIN EN 60068-2 and DIN EN 60731-3-2
- Climatic conditions Class 2K3
- Mechanical conditions Class 2M2
- Temperature range -20...60 °C
- Humidity <90% r.h. (noncondensing)
Operation DIN EN 60721-3-3
- Climatic conditions Class 3K3
- Mechanical conditions Class 3M2
- Temperature range 0...60 °C
- Humidity <85% r.h. (noncondensing)
Warning!
Condensation, formation of ice and ingress of water are not permitted!
Warning!
The AGU2.56... may only be plugged into the respective socket on the LMS14...
or OCI432...!
General unit data
Environmental
conditions
