397/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.23.9 Relay outputs QX
Note!
Output QX4 is a stepper motor output and is referred to as WX1 in the illustration
of chapter Terminals of LMS14… complete (Basic).
Line no. Operating line
5890
5891
5892
Relay output QX1, 2, 3
None
Circulating pump Q4
El imm heater DHW K6
Collector pump Q5
Cons circuit pump VK1 Q15
Boiler pump Q1
Bypass pump Q12
Alarm output K10
2nd pump speed HC1 Q21
2nd pump speed HC2 Q22
2nd pump speed HC3 Q23
Heat circuit pump HC3 Q20
Cons circuit pump VK2 Q18
System pump Q14
Heat gen shutoff valve Y4
Solid fuel boiler pump Q10
Time program 5 K13
Buffer return valve Y15
Solar pump ext exch K9
Solar ctrl elem buffer K8
Solar ctrl elem swi pool K18
Swimming pool pump Q19
Cascade pump Q25
St tank transfer pump Q11
DHW mixing pump Q35
DHW interm circ pump Q33
Heat request K27
Refrigeration request K28
Heat circuit pump HC1 Q2
Heat circuit pump HC2 Q6
DHW ctrl elem Q3
Instant WH ctrl elem Q34
Water refill K34
2nd boiler pump speed Q27
Status output K35
Status information K36
Flue gas damper K37
Fan shutdown K38
dT controller 1 K21
dT controller 2 K22
The relay output settings assign the appropriate functions.
None
Relay output with no function.
Relay output QX1, 2, 3
