Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.25 Faults
When a fault
is pending, the respective error message can be displayed on the info
level by pressing the Info button. The display provides information on the cause of fault.
6.25.1 Message
Line no. Operating line
6700 Message
Line no. Operating line
6705 SW diagnostic code
An internal software error currently pending is displayed here together with the
diagnostic code indicating where the error occurred.
Line no. Operating line
6706 Burn ctrl phase lockout pos
A fault currently pending is displayed here together with the lockout phase indicating
where the fault occurred.
6.25.2 Acknowledgements
Line no. Operating line
6710 Reset alarm relay
No
Yes
If a fault is pending, an alarm can be triggered via relay QX... This relay must be
appropriately configured. The setting can be used to reset the alarm relay.
Message
SW diagnostic code
Burn ctrl phase
lockout pos
Reset alarm relay
