Siemens LMS14 User Manual

357/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.21.8 Configuration
Basics of instantaneous water heater (function)
To configure an instantaneous water heater, the DHW sensor connected to terminal
B3/B38 must be parameterized as sensor B38. For that, use parameter DHW sensor
(5730) and select DHW outlet sensor B38.
Parameter DHW controlling element (5731) is used to select the type of controlling
element (diverting valve or charging pump). Control of this controlling element must be
assigned to at least one output (QX1, QX2, QX3, QX4/WX1) (parameters Relay output
QX1 (5890), Relay output QX2 (5891), Relay output QX3 (5892), Relay output QX4
(5894)). Here, select Instant WH ctrl element Q34. For the control of a diverting valve,
output QX3 has a changeover contact.
Parameter Aqua booster (5550) is used to determine whether there is an aqua booster.
Line no. Operating line
5550 Aqua booster
No
Yes
Yes, wo gradient detection
Aqua booster setting.
No
No aqua booster configured.
Yes
Aqua booster configured.
Yes, wo gradient detection
Aqua booster configured, but detection of consumption via gradient is not activated.
Consumption is detected via flow switch or flow.
Line no. Operating line
5489 Overrun via Inst WH
5530 Pump speed min
5531 Pump speed max
5535 Pump speed min OEM
5536 Pump speed max OEM
5537 Starting speed
5730 DHW sensor
5731
DHW controlling element
5890 Relay output QX1
5891 Relay output QX2
5892 Relay output QX3
Configuration of
instantaneous water
heater
A
qua booster
A
dditional parameters
