Building Technologies Division User Manual LMS14… CC1U7471en
8 Technical data 28.01.2015
8 Technical data
8.1 LMS14… basic unit
8.1.1 General data
Mains voltage (rated voltage) AC 230 V
Mains frequency 50 Hz to DIN EN 298
Power consumption
- Operation Max. 14 W
- Power pack Max. 14 W
Rated surge voltage category III (as per DIN EN 60664)
Degree of protection IP00
IP40 (to be ensured when fitted inside the
boiler)
Safety class Unit designed for use in equipment of
safety class I
Degree of pollution 2
Software classes As per DIN EN 60730-2-5
- Controller part Class A
- Burner control Class C
Dimensions (L x W x D) 230 x 150 x 30 mm
Weight Approx. 0.254 kg
Unit fuse 2 x T6.3H250 internal
Mounting position Optional
Caution!
When making 100% inspections as per DIN EN 60335-1, Addendum A, only AC
voltage may be applied. If DC voltage tests are conducted, the LMS14... can get
damaged.
8.1.2 Environmental conditions
Storage DIN EN 60721-3-1
- Climatic conditions Class 1K3
- Mechanical conditions Class 1M2
- Temperature range -20...60 °C
- Humidity <90% r.h. (noncondensing)
Transport DIN EN 60731-3-2
- Climatic conditions Class 2K3
- Mechanical conditions Class 2M2
- Temperature range -20...60 °C
- Humidity <90% r.h. (noncondensing)
Operation DIN EN 60721-3-3
- Climatic conditions Class 3K3
- Mechanical conditions Class 3M2
- Temperature range 0...60 °C
- Humidity <85% r.h. (noncondensing)
Warning!
Condensation, formation of ice and ingress of water are not permitted!
