220/617
Building Technologies Division User Manual LMS14... CC1U7471en
6 The settings in detail 07.05.2014
6.11.15 Output data
Line no. Operating line
2330 Output nominal
Line no. Operating line
2331 Output basic stage
These settings are required when several boilers with different capacities operate in a
cascaded system.
Line no. Operating line
2334 Output at pump speed min
If option Pump modulation (2320) is selected, the boiler pump is operated at minimum
speed until the burner output set on Output at pump speed min (2334) is reached, and
at maximum speed from the burner output set on Output at pump speed max (2335).
If the burner’s output lies between these 2 values, the boiler pump’s speed is calculated
through linear conversion.
Line no. Operating line
2335 Output at pump speed max
If option Pump modulation (2320) is selected, the boiler pump is operated at minimum
speed until the burner output set on Output at pump speed min (2334) is reached, and
at maximum speed from the burner output set on Output at pump speed max (2335).
If the burner’s output lies between these 2 values, the boiler pump’s speed is calculated
through linear conversion.
Output nominal
Output basic stage
Output at pump speed min
Output at pump speed
max
