Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.43 Production
Line no. Operating line
[5000.1] SW version number
Software version number used to unambiguously identify the version installed in the
unit.
Line no. Operating line
[4763.1]
Histo last 4 para set
The LMS14... stores the last 4 types of parameterization from the parameter stick or the
ACS420 PC software.
Both user level and type of parameterization are stored.
The information is provided in the form of a string comprising 16 numbers.
2 numbers always belong together, and 4 numbers describe the parameterization.
The string contains the last 4 parameterizations.
The fist 2 numbers describe the type of parameterization, the next 2 the user level.
The parameterization made last is always the first in the string.
Time information provided about the parameterizations is not stored.
Example of evaluation:
Value shown by the ACS700/ACS790 PC software: 0204510352030207
Subdivision into 4 groups of parameterization: 0204 - 5103 - 5203 - 0207
Last parameterization:
0204  02, 04  02: Parameterized with ACS420 PC software
04: User level OEM2
Last but 1 parameterization:
5103  51, 03  51: Parameterized with stick
03: User level OEM headquarters
Last but 2 parameterization:
5203  52, 03  52: Online DD parameterized with stick
03: User level OEM headquarters
Last but 3 parameterization:
0207  02, 07  02: Parameterized with ACS420 PC software
07: User level Commissioning
