6.11.31 Input configuration dynamic pressure supervision
Line no. Operating line
[4195.1] Dyn press supervision
None
With input H1
With input H3
To acquire the water pressure, different inputs can be configured (also simultaneously),
allowing the water pressure to be monitored in parallel by static pressure supervision.
For dynamic pressure supervision, only connections configured locally on the LMS14
can be used, due to the dynamic requirements (resolution/timing). For this reason, Dyn
press supervision can be used to select the connection whose signal serves for
dynamic pressure supervision. Also refer to chapter Water pressure sensor.
None
No dynamic pressure supervision.
Via input H1
Dynamic pressure supervision via input H1.
Via input H3
Dynamic pressure supervision via input H3.
6.11.32 Input configuration flow supervision
A number of controller functions can access the measured flow value. For that purpose,
flow supervision must be activated. Activation is effected via Flow supervision [4196.1].
The way the value is then used with the individual controller functions is described with
the respective functions.
Line no. Operating line
[4196.1] Flow supervision
None
With input H4
The input to be used for flow supervision can be selected here.
None
No flow supervision.
With input H4
Flow supervision via input H4.
Dyn press supervision
Flow supervision
