Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.23.15 BX extension modules
Caution!
Under the most unfavorable conditions, the signals from the extension
modules to the LMS14..., and vice versa, may take up to 40 seconds to be
refreshed in the LMS14… via the BSB. This can lead to functional restrictions
and detrimental effects on the limit thermostat functions. For such functions,
use BX1, BX2, BX3 or BX4.
Note!
Sensor input BX4 is firmly assigned to sensor B7.
Line no. Operating line
6040
6041
6042
6043
6044
6045
Sensor input BX21 module 1
Sensor input BX22 module 1
Sensor input BX21 module 2
Sensor input BX22 module 2
Sensor input BX21 module 3
Sensor input BX22 module 3
None
DHW sensor B31
Collector sensor B6
DHW circulation sensor B39
Buffer sensor B4
Buffer sensor B41
Flue gas temp sensor B8
Common flow sensor B10
Solid fuel boiler sensor B22
DHW charging sensor B36
Buffer sensor B42
Common return sensor B73
Cascade return sensor B70
Swimming pool sensor B13
Solar flow sensor B63
Solar return sensor B64
Primary exch sensor B26
The relay output settings assign the appropriate functions.
None
Sensor input with no function.
DHW sensor B31
DHW storage tank sensor at the bottom.
Collector sensor B6
This sensor is required for the solar function.
DHW circulation sensor B39
DHW circulation sensor/standby sensor.
Buffer sensor B4
Buffer storage tank sensor at the top.
Sensor input BX...
module 1, 2, 3
