8.3.2 NTC 10k
T [°C] R [] T [°C] R [] T [°C] R []
-30 175203 50 3605 130 298
-25 129289 55 2989 135 262
-20 96360 60 2490 140 232
-15 72502 65 2084 145 206
-10 55047 70 1753 150 183
-5 42158 75 1481 155 163
0 32555 80 1256 160 145
5 25339 85 1070 165 130
10 19873 90 915 170 117
15 15699 95 786 175 105
20 12488 100 677 180 95
25 10000 105 586 185 85
30 8059 110 508 190 77
35 6535 115 443 195 70
40 5330 120 387 200 64
45 4372 125 339
8.3.3 Pt1000
T [°C]
R []
T [°C]
R []
T [°C]
R []
–30 882.2 50 1194 130 1498.3
–25 901.9 55 1213.2 135 1517.1
–20 921.6 60 1232.4 140 1535.8
–15 941.2 65 1251.6 145 1554.6
–10 960.9 70 1270.8 150 1573.3
–5 980.4 75 1289.9 155 1591.9
0 1000 80 1309 160 1610.5
5 1019.5 85 1328 165 1629.1
10 1039 90 1347.1 170 1647.7
15 1058.5 95 1366.1 175 1666.3
20 1077.9 100 1385.1 180 1684.8
25 1097.3 105 1404.0 185 1703.3
30 1116.7 110 1422.9 190 1721.7
35 1136.1 115 1441.8 195 1740.2
40 1155.4 120 1460.7 200 1758.6
45 1174.7 125 1479.5
