405/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.23.11 Inputs H1/H3/H4/H5/H6/H7
Warning!
If, with the safety-related GP configuration (9612), function Gas pressure
switch is selected, Function input H6 (6008) only allows the selection of None.
The safety-related GP configuration (9612) parameter must be set to GP not
connected in order for Function input H6 (6008) to be evaluated.
If, then, Function input H6 (6008) is used to select function Gas pressure
switch, the latter is not safety-related.
Warning!
If, for input H7 with the safety-related LP configuration (9611), a safety-related
function Air pressure switch is parameterized, Function input H7 (6011) only
allows the selection of None.
Line no. Operating line
5950
5960
5970
5977
6008
6011
Function of input Hx
None
Optg mode change HCs+DHW
Optg mode changeover DHW
Optg mode changeover HCs
Optg mode changeover HC1
Optg mode changeover HC2
Optg mode changeover HC3
Heat generation lock
Error/alarm message
Consumer request VK1
Consumer request VK2
Release swi pool source heat
Excess heat discharge
Release swi pool solar
Operating level DHW
Operating level HC1
Operating level HC2
Operating level HC3
Room thermostat HC1
Room thermostat HC2
Room thermostat HC3
DHW flow switch
DHW thermostat
Pulse count
Checkb sign flue gas damper
Start prevention
Boiler flow switch
Boiler pressure switch
Gas pressure switch
Flow measurement Hz
Consumer request VK1 10V
Consumer request VK2 10V
Pressure measurement 10V
Output request 10V
Function of input H1, H3,
H4, H5, H6, H7
