Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.34.7 Chimney drying
Line no. Operating line
9650 Chimney drying
Off
Temporarily
Permanently
When chimney drying is activated, the function is started after shutdown when changing
to Standby. Chimney drying can be interrupted by any request for heat and can be
restarted when the sequence of phases returns to Standby.
Off
Function is deactivated.
Temporarily
The duration of chimney drying is dependent on parameter Duration chimney drying
(9652).
Permanently
Chimney drying is continuously performed in Standby mode.
Line no. Operating line
9651 Req speed chimney drying
Predefined speed that shall be used for drying the chimney.
Line no. Operating line
9652 Duration chimney drying
Duration of chimney drying if temporal limitation is required.
Chimney drying
Req speed chimney
drying
Duration chimney
drying
