Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.23.12 Extension modules
Caution!
Under the most unfavorable conditions, the signals from the extension
modules to the LMS14..., and vice versa, may take up to 40 seconds to be
refreshed via the BSB. This can lead to functional restrictions and detrimental
effects on the limit thermostat functions. For such functions, use BX1, BX2,
BX3, BX4/QX1, QX2, QX3, QX4 (only valves) /P1/H1, H3, H4, H5, H6 or H7.
Note!
Sensor input BX4 is firmly assigned to sensor B7.
Line no. Operating line
6020
6021
6022
Function extension module x
None
Multifunctional
Heating circuit 1
Heating circuit 2
Heating circuit 3
Return temp controller
Solar DHW
Prim contr/system pump
None
Function is deactivated.
Multifunctional
The choice of functions that can be assigned to the multifunctional inputs/outputs
appear as …
Relay output QX21 module 1 (6030),
Relay output QX22 module 1 (6031),
Relay output QX23 module 1 (6032),
Relay output QX21 module 2 (6033),
Relay output QX22 module 2 (6034),
Relay output QX23 module 2 (6035),
Relay output QX21 module 3 (6036),
Relay output QX22 module 3 (6037),
Relay output QX23 module 3 (6038),
Sensor input BX21 module 1 (6040),
Sensor input BX22 module 1 (6041),
Sensor input BX21 module 2 (6042),
Sensor input BX22 module 2 (6043),
Sensor input BX21 module 3 (6044), and
Sensor input BX22 module 3 (6045).
Heating circuit 1
For this application, the respective settings of operating page Heating circuit 1 can be
adapted.
Heating circuit 2
For this application, the respective settings of operating page Heating circuit 2 can be
adapted.
Heating circuit 3
For this application, the respective settings of operating page Heating circuit 3 can be
adapted.
Function extension
module 1, 2, 3
