Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.23 Configuration
Note!
During the reconfiguration of the LMS14..., following might occur:
 Errors that have already been identified continue to be present.
Such errors can be canceled via power OFF or by making a reset, depending on
the kind of response to the error.
Example:
A water pressure error is pending and, in this error state, the error is rectified
through parameterization
 Errors are identified and the LMS14... goes to lockout, depending on the type of
error.
Example:
A water pressure sensor is configured with Lockout as a response to the error,
but no sensor is connected, or the selection was not wanted.
In that case, the selected sensor is to be connected or the configuration must be
matched to the connected type of sensor.
Then, a reset must be made or power OFF is required.
Line no. Operating line
5700 Presetting
Changed
Unchanged
The plant diagrams shown in chapter Applications can be preselected by entering the
diagram number. The plant diagram obtained is the result of preselection and
connected sensors.
Note!
The sensors shown on the desired plant diagram must be connected, thus ensuring
that automatic sensor identification does not detect some other plant diagram.
By making the preselection, the following parameter values are set:
Line no. Function 1
(No DHW)
2
(DHW storage
tank)
3
(Instantaneous
water heater)
4
(DHW
stratification
storage tank)
870 With buffer (HC1) Yes Yes Yes Yes
872 With primary controller/system
pump (HC1)
Yes Yes Yes Yes
1170 With buffer storage tank (HC2) Yes Yes Yes Yes
1172 With primary controller/system
pump (HC2)
Yes Yes Yes Yes
1470 With buffer storage tank (HC3) Yes Yes Yes Yes
1472 With primary controller/system
pump (HC3)
Yes Yes Yes Yes
1600 Operating mode DHW On On On On
1610 Nominal DHW setpoint 55 °C 60 °C 45 °C 60 °C
1640 Legionella function Fixed weekday Periodically Off Periodically
1878 With buffer storage tank (VK1) Yes Yes Yes Yes
1880 With primary controller/system
pump (VK1)
Yes Yes Yes Yes
1928 With buffer storage tank (VK2) Yes Yes Yes Yes
1930 With primary controller/system
pump (VK2)
Yes Yes Yes Yes
1978 With buffer storage tank
(swimming pool)
Yes Yes Yes Yes
Presetting
