Siemens LMS14 User Manual

425/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.23.16 H2 extension modules 1/2/3
Warning!
Under the most unfavorable conditions, the signals from the extension
modules to the LMS14..., and vice versa, may take up to 40 seconds to be
refreshed in the LMS14… via the BSB.
This can lead to functional restrictions and detrimental effects on the limit
thermostat functions. For such functions, use H1, H3, H4, H5, H6 or H7.
Line no. Operating line
6046
6054
6062
Function input H2 module 1
Function input H2 module 2
Function input H2 module 3
None
Optg mode change HCs+DHW
Optg mode changeover DHW
Optg mode changeover HCs
Optg mode changeover HC1
Optg mode changeover HC2
Optg mode changeover HC3
Heat generation lock
Error/alarm message
Consumer request VK1
Consumer request VK2
Release swi pool source heat
Excess heat discharge
Release swi pool solar
Operating level DHW
Operating level HC1
Operating level HC2
Operating level HC3
Room thermostat HC1
Room thermostat HC2
Room thermostat HC3
DHW flow switch
DHW thermostat
Limit thermostat HC
Start prevention
Boiler flow switch
Boiler pressure switch
Consumer request VK1 10V
Consumer request VK2 10V
Pressure measurement 10V
Output request 10V
Function input H2 module
x
