Building Technologies Division User Manual LMS14... CC1U7471en
1 Summary 28.01.2015
Product no.
(ASN)
Description
Documentation
no.
QAD36/101 Strap-on temperature sensor NTC 10k CC1Q1808
QAZ36.522/109 Immersion temperature sensor NTC 10k CC1Q1843
QAZ36.526/109 Immersion temperature sensor NTC 10k CC1Q1843
OCI430... Interface module for PC-LMS... connection CC1N7635
OCI700 Service tool CC1E5655
TQG42...
Ignition module, combined with connection line for LMS14..., suitable
for VGU smart gas valves
CC1N7630
VGU7xS... Combination gas valves CC1N7668
VGU8xS... Combination gas valves CC1N7668
ACS420 Software for OCI430... ---
ACS432 Parameter stick manager CC1J7474
ACS435 Setup manager CC1J7471
ACS700 Remote supervision software/parameterization software for OCI700 Software CD
LMS14... are digital boiler management units (BMUs) for use with gas-fired
appliances equipped with premix burners. They are used for startup, control and
supervision of premix burners with capacities from <10 kW to 1 MW in intermittent
operation with direct ignition of the main flame.
The OEM must make certain that the LMS14… are suited for the application in
question.
The LMS14... provide all supervisory and control functions required for burner
operation, space heating and DHW heating. They also offer modular system
extensions in the form of integrated communication interfaces. Output modulation
is performed via a PWM-controlled fan with pneumatic gas-air ratio control.
1.2 Target group of users
Target group of users are OEMs
LMS14…
