7.10.4 Configuration of CU3xx/TMxx I/Os
Overview
The configuration is performed in a similar way as for the onboard I/Os for the
SIMOTION D410-2, i.e. the I/Os can be
●
BICO-interconnected (use as drive I/O)
● Used by SIMOTION
See also Section SIMOTION D410-2 Configuring I/Os (Page 208)
Note
If
symbolic assignment is subsequently activated for a project in which telegrams have already
been configured and interconnected, this project can be changed together with the BICO
interconnections!
For this reason, make a backup copy of your project before activating the symbolic assignment.
The TM15 DI/DO and the TM31 are particularly affected here (see Section Symbolic
assignment / adaptation (Page 139)).
Commissioning (software)
7.10 Configuring drive-related I/Os
SIMOTION D410-2
210 Commissioning and Hardware Installation Manual, 01/2015
