4.8.4 Rules for the laying of PROFIBUS cables
Laying of bus cable
During laying of the PROFIBUS cable, you must:
● Not twist the cable
● Not stretch the cable
● Not squeeze the cable
Supplementary conditions
In addition, when laying a bus cable for indoor use, you must take into account the following
supplementary conditions (dA = external cable diameter):
Table 4-6 Supplementary conditions for the laying of PROFIBUS cables
Characteristics Supplementary conditions
Bending radius for a single bend 80 mm (10xdA)
Bending radius for multiple bends 160 mm (20xdA)
Permissible temperature range for cable routing -5° C to +50° C
Temperature range for storage and stationary operation -30° C to +65° C
Additional references
Length codes for prefabricated cables can be found in:
●
Catalog
PM 21; SIMOTION Motion Control, SINAMICS S120 and Motors for Production
Machines
● Catalog IK PI ,Industrial Communication
4.8.5 Connecting PROFIBUS DP (interface X21 and X24)
PROFIBUS cables are connected to the corresponding interface via a bus connector.
Table 4-7 SIMOTION D410-2 PROFIBUS interfaces
D410-2 DP D410-2 DP/PN
PROFIBUS DP/MPI interface X21 X21
PROFIBUS DP interface X24 –
Connecting
4.8 Connecting PROFIBUS/MPI
SIMOTION D410-2
Commissioning and Hardware Installation Manual, 01/2015 63
