Description
2
2.1 System overview
SIMOTION D
SIMOTION D is a drive-based version of SIMOTION based on the SINAMICS S120 drive
family.
With SIMOTION D, the SIMOTION PLC and motion control functionalities as well as the
SINAMICS S120 drive software run on shared control hardware.
SIMOTION D is available in two versions:
●
SIMOTION D410-2 is a compact Control Unit predestined for single-axis applications.
● SIMOTION D4x5-2 is a Control Unit for multi-axis applications in the SINAMICS S120
booksize format.
The following performance variants of the SIMOTION D4x5-2 Control Units are offered:
Control Unit Performance variant Range of applications
SIMOTION D425-2 BASIC performance For up to 16 axes
SIMOTION D435-2 STANDARD performance For up to 32 axes
SIMOTION D445-2 HIGH performance For up to 64 axes
SIMOTION D455-2 ULTRA-HIGH performance For up to 128 axes or applications with very
short control cycles
Note
The SIMOTION D410-2 is described in this manual.
Separate manuals are available for the SIMOTION D4x5-2 and the SIMOTION D4x5 and
SIMOTION D410 predecessor modules.
SIMOTION D is an integral part of the Totally Integrated Automation (TIA) concept. TIA is
characterized by integrated data management, configuration, and communication for all
products
and systems. Thus, an extensive toolbox of automation modules is also available for
the SIMOTION D410-2.
Note
In order to cover all variants of SIMOTION D in blocksize format, the product will be referred
to as "D410-2". Specific product designations will be used for information that applies only to
one product version, e.g. D410-2 DP/PN.
SIMOTION D410-2
Commissioning and Hardware Installation Manual, 01/2015 23
