Siemens SINUMERIK 808D Parameter Manual

18662 MM_NUM_SYNACT_GUD_BOOL N02 -
- Number of configurable GUD variables of type Boolean DWORD PowerOn
-
808d-me42 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-me62 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-te42 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-te62 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-mte40 9 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 7/2 M
808d-mte60 9 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 7/2 M
Description: The MD18662 $MN_MM_NUM_SYNACT_GUD_BOOL[ ] can be used to extend individual GUD blocks
by additional channel-specific parameter areas of type Boolean. The GUD blocks are
differentiated by the field index:
MD18662 $MN_MM_NUM_SYNACT_GUD_BOOL[0] = <value> -> extension of the SGUD block
MD18662 $MN_MM_NUM_SYNACT_GUD_BOOL[1] = <value> -> extension of the MGUD block
MD18662 $MN_MM_NUM_SYNACT_GUD_BOOL[2] = <value> -> extension of the UGUD block
MD18662 $MN_MM_NUM_SYNACT_GUD_BOOL[3] = <value> -> extension of the GUD4 block
MD18662 $MN_MM_NUM_SYNACT_GUD_BOOL[8] = <value> -> extension of the GUD9 block
In each case, fields with the following properties are created:
Data type BOOL
Field size corresponding to <value> of the relevant machine data
Predefined names:
SYG_BS[ ] -> Synact parameter of type Boolean in the SGUD block
SYG_BM[ ] -> Synact parameter of type Boolean in the MGUD block
SYG_BU[ ] -> Synact parameter of type Boolean in the UGUD block
SYG_B4[ ] -> Synact parameter of type Boolean in the GUD4 block
....
SYG_B9[ ] -> Synact parameter of type Boolean in the GUD9 block
The parameters can be read and written both by the part program and also via
synchronous actions.
18663 MM_NUM_SYNACT_GUD_AXIS N02 -
- Number of configurable GUD variables of type Axis DWORD PowerOn
-
808d-me42 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-me62 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-te42 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-te62 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-mte40 9 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 7/2 M
808d-mte60 9 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 7/2 M
Description: The MD18663 $MN_MM_NUM_SYNACT_GUD_AXIS[ ] can be used to extend individual GUD blocks
by additional channel-specific parameter areas of type AXIS. The GUD blocks are
differentiated by the field index:
MD18663 $MN_MM_NUM_SYNACT_GUD_AXIS[0] = <value> -> extension of the SGUD block
MD18663 $MN_MM_NUM_SYNACT_GUD_AXIS[1] = <value> -> extension of the MGUD block
MD18663 $MN_MM_NUM_SYNACT_GUD_AXIS[2] = <value> -> extension of the UGUD block
MD18663 $MN_MM_NUM_SYNACT_GUD_AXIS[3] = <value> -> extension of the GUD4 block
MD18663 $MN_MM_NUM_SYNACT_GUD_AXIS[8] = <value> -> extension of the GUD9 block
In each case, fields with the following properties are created:
Data type AXIS
Machine data
