Siemens SINUMERIK 808D Parameter Manual

1110 ENABLE_LADDER_DB_ADDRESSES - -
- DB representation in the PLC ladder viewer BOOLEAN Immediately
-
- - 1 0 1 7/2 M
Description: DB representation in the PLC ladder viewer
0 - VB representation of the PLC signals
1 - DB representation of the PLC signals
1111 ENABLE_LADDER_EDITOR - -
- Activate/deactivate PLC ladder editor BOOLEAN Immediately
-
- - 1 0 1 7/2 M
Description: Activate/deactivate PLC ladder editor
0 - No editing functionality for PLC programs
1 - Activate edit functionality for PLC programs
1113 EASYXML_FUNCTION_MASK - -
- EasyXML function mask DWORD PowerOn
-
- - 0 0 0xFFFF 1/1 M
Description: Bit 0: The TrueType fonts are set for displaying texts.
- 1: set the TrueType fonts explicitly for displaying texts for compatibility
- 0: Bitmap fonts or overwritten with TRUETYPEFONT tag
Bit 1: no autozoom for displays
- 1: no autozoom for the displays used in the script for compatibility
- 0: autozoom
Bit 2 - 15: reserved
203 DISPLAY_RESOLUTION - -
- Display resolution for mm dimension system BYTE Immediately
-
- 0 3 0 5 3/2 M
Description: This MD is used to define the number of decimal places of the position display, for
linear axes in metric systems, in general for rotary axes.
Spindle positions are treated like rotary axis positions.
The position display is displayed with a max. of 10 characters including signs and
decimal places. A positive sign is not displayed.
By default 3 digits are displayed after the decimal point.
MD value=3: display resolution = 10-3 [mm] or [degree],
Related to:
MD 10200: INT_INCR_PER_MM bzw. MD 10210: INT_INCR_PER_DEG
204 DISPLAY_RESOLUTION_INCH - -
- Display resolution for inch system of measurement BYTE Immediately
-
- 0 4 0 5 3/2 M
Machine data
3.1 Display machine data
Parameter Manual
24 List Manual, 01/2017
