Designator Meaning
DWORD 32-bit value
● As an INTEGER value: -2147483648 to 2147483647
● As a hexadecimal value: 0000 0000 to FFFF FFFF
UNSIGNED DWORD
I32-bit value
● As an INTEGER value: 0 to 4294967295
● As a hexadecimal value: 0000 0000 to FFFF FFFF
DOUBLE 64-bit value
● Floating point value: ±4.19 × 10
-307
to ±1.57 × 10
308
FLOAT DWORD Real value: ±7.43 × 10
-37
to 3.37 × 10
38
UBYTE Integer value: 0 to 255
LONG Integer value: 4294967296 to 4294967295
System
Specifies the control system for which the data with the entered values applies.
By default, the entered values apply for both SINUMERIK 808D/SINUMERIK 808D
ADVANCED T (Turning) and SINUMERIK 808D/SINUEMRIK 808D ADVANCED M (Milling).
If no "default" entry exists, the data only applies for the control variants specified:
808d-te62 SINUMERIK 808D ADVANCED T (Turning)
808d-me62 SINUMERIK 808D ADVANCED M (Milling)
808d-te42 SINUMERIK 808D (Turning)
808d-me42 SINUMERIK 808D (Milling)
Default values
Specifies a default value fort he machine data. If the default values for the channels are
different, they are separated with a comma ",".
Range of values (minimum/maximum value)
Specifies the limits for the entered values. If no range of value is specified, the data type
determines the input limits, and the field is marked with a dash "-".
Protection
The control system provides a concept of access levels for enabling data areas. The access
levels correspond with protection levels 0 to 7 (0: the highest level; 7: the lowest level). You
can view such information from the table shown as below:
Protection level Access level Default password Target group
0 Siemens - Reserved for Siemens
1 Manufacturer SUNRISE Machine manufacturers
2 Reserved
Explanation of machine data and setting data
2.1 Data in the list
Parameter Manual
List Manual, 01/2017 15
