Application Generally, the S function is transferred channel-specific in DB2500
DBD4000 ... as floating-point value to the PLC.
In this IS "S function for the spindle", this output is realized to the PLC as
floating-point value for specific axes:
● S... as spindle speed in rpm (programmed value)
● S... as constant cutting speed in m/min or ft/min for G96
The following S functions are not output here:
●
S... as programmed spindle speed limiting G25
● S... as programmed spindle speed limiting G26
● S... as the dwell time in spindle revolutions
corresponding to ... IS "M function for spindle" (DB370x DBD0), axis-specific
IS "Transferred S function" (DB2500 DBD4000 ...), channel-specific
Note for the reader Function Manual Basic Functions S1
5.8.2 Signals to axis / spindle
DB380x
DBB0
Feedrate override (axis-specific)
Signal(s) to axis (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
Parameter Manual
List Manual, 01/2017 425
