2024 Float value (REAL/4 byte)
2028 Float value (REAL/4 byte)
6.12.4 User alarm: Configuring (MD 14516 USER_DATA_PLC_ALARM)
DB4500 Signals from NCK [r8]
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
3000 Alarm response/cancel criteria, alarm 700000
3001 Alarm response/cancel criteria, alarm 700001
3002 Alarm response/cancel criteria, alarm 700002
... ...
3247 Alarm response/cancel criteria, alarm 700247
Note
For more information about how to configure user alarms, see Section "Editing PLC alarm
texts".
6.13 Signals, synchronized actions
6.13.1 Signals, synchronized actions to channel
DB4600 Signals, synchronized actions to channel [r/w]
PLC -> HMI interface
Byte Bit 7
Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Deactivate synchronized action with ID...
ID8 ID7 ID6 ID5 ID4 ID3 ID2 ID1
1 Deactivate synchronized action with ID...
ID16 ID15 ID14 ID13 ID12 ID11 ID10 ID9
2 Deactivate synchronized action with ID...
ID24 ID23 ID22 ID21 ID20 ID19 ID18 ID17
PLC user interface
6.13 Signals, synchronized actions
Parameter Manual
List Manual, 01/2017 503
