6.8.4 Transferred M functions
DB2500 M functions from NCK channel [r]
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
3000 M function 1 (DINT)
3004 Extended address M function 1 (byte)
3008 M function 2 (DINT)
3012 Extended address M function 2 (byte)
3016 M function 3 (DINT)
3020 Extended address M function 3 (byte)
3024 M function 4 (DINT)
3028 Extended address M function 4 (byte)
3032 M function 5 (DINT)
3036 Extended address M function 5 (byte)
6.8.5 Transferred S functions
DB2500 S functions from NCK channel [r]
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
4000 S function 1 (REAL) (DINT)
4004 Extended address S function 1 (byte)
4008 S function 2 (REAL)
4012 Extended address S function 2 (byte)
4016
4020
6.8.6 Transferred D functions
DB2500 D functions from NCK channel [r]
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
5000 D function 1 (DINT)
5004
PLC user interface
6.8 Auxiliary functions transfer from NC channel
Parameter Manual
486 List Manual, 01/2017
