Field size corresponding to <value> of the relevant machine data
Predefined names:
SYG_AS[ ] -> Synact parameter of type AXIS in the SGUD block
SYG_AM[ ] -> Synact parameter of type AXIS in the MGUD block
SYG_AU[ ] -> Synact parameter of type AXIS in the UGUD block
SYG_A4[ ] -> Synact parameter of type AXIS in the GUD4 block
....
SYG_A9[ ] -> Synact parameter of type AXIS in the GUD9 block
The parameters can be read and written both by the part program and also via
synchronous actions.
18664 MM_NUM_SYNACT_GUD_CHAR N02 -
- Configurable GUD variable of type Char DWORD PowerOn
-
808d-me42 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-me62 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-te42 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-te62 1 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 0/0 S
808d-mte40 9 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 7/2 M
808d-mte60 9 0, 0, 0, 0, 0, 0, 0, 0... 0 32767 7/2 M
Description: The MD18664 $MN_MM_NUM_SYNACT_GUD_CHAR[ ]
can be used to extend individual GUD blocks by additional
channel-specific parameter areas of type CHAR.
The GUD blocks are differentiated by the field index:
MD18664 $MN_MM_NUM_SYNACT_GUD_CHAR[0] = <value> -> extension of the SGUD block
MD18664 $MN_MM_NUM_SYNACT_GUD_CHAR[1] = <value> -> extension of the MGUD block
MD18664 $MN_MM_NUM_SYNACT_GUD_CHAR[2] = <value> -> extension of the UGUD block
MD18664 $MN_MM_NUM_SYNACT_GUD_CHAR[3] = <value> -> extension of the GUD4 block
MD18664 $MN_MM_NUM_SYNACT_GUD_CHAR[8] = <value> -> extension of the GUD9 block
In each case, fields with the following properties are created:
Data type CHAR
Field size corresponding to <value> of the relevant machine data
Predefined names:
SYG_CS[ ] -> Synact parameter of type CHAR in the SGUD block
SYG_CM[ ] -> Synact parameter of type CHAR in the MGUD block
SYG_CU[ ] -> Synact parameter of type CHAR in the UGUD block
SYG_C4[ ] -> Synact parameter of type CHAR in the GUD4 block
....
SYG_C9[ ] -> Synact parameter of type CHAR in the GUD9 block
The parameters can be read and written both by the part program
and also via synchronous actions.
18665 MM_NUM_SYNACT_GUD_STRING N02 -
- Configurable GUD variable of type STRING DWORD PowerOn
-
808d-me42 1 0, 0, 0, 0, 0, 0, 0, 0... 0 25 0/0 S
808d-me62 1 0, 0, 0, 0, 0, 0, 0, 0... 0 25 0/0 S
808d-te42 1 0, 0, 0, 0, 0, 0, 0, 0... 0 25 0/0 S
808d-te62 1 0, 0, 0, 0, 0, 0, 0, 0... 0 25 0/0 S
Machine data
3.2 General machine data
Parameter Manual
114 List Manual, 01/2017
