Siemens SINUMERIK 808D Parameter Manual

ID Data area
C06 Monitoring/limiting functions
C07 Transformations
C08 Corrections/compensations
C09 Technological functions
C10 Standard machine
C11 NC language, ISO dialect
Axis machine data
A01 Configuration (including memory)
A02 Measuring system
A03 Machine geometry
A04 Velocities / accelerations
A05 Monitoring/limiting functions
A06 Spindle
A07 Controller data
A08 Status data
A09 Corrections/compensations
A10 Technological functions
A11 Standard machine
A12 NC language, ISO dialect
Data type
In the "Data
type" field, the short designators indicate the data types. They have the following
meanings:
Designator Meaning
BOOLEAN Boolean value
● 1: TURE
● 0: FALSE
BYTE I8-bit value
● As an INTEGER value: -128 to 127
● As a hexadecimal value: 00 to FF
●
As a character as per ASCII character set, e.g. "a"
STRING Sequence of characters (max. 16)
WORD 16-bit value
●
As an INTEGER value: 0 to 65535
● As a hexadecimal value: 0000 to FFFF
UNSIGNED WORD
I16-bit value
● As an INTEGRER value: 0 to 65535
● As a hexadecimal value: 0000 to FFFF
INTEGER I16-bit value (here defined locally)
● INTEGER value: -32768 to 32767
Explanation of machine data and setting data
2.1 Data in the list
Parameter Manual
14 List Manual, 01/2017
