Siemens SINUMERIK 808D Parameter Manual

Par. No. Name Min Max Factory
setting
Unit Data type Effective Can be
changed
p1821[0...n] Direction of rotation 0 1 [0] 0 - I16 IM -
Description:
Setting
to change
the direction of rotation. If the parameter is changed, it reverses the direction of rotation of
the motor and the encoder actual value without changing the setpoint.
Dependency: F07434
Caution:
Changing the direction using p1820 or p1821 is not recognized by the "Safe Direction without encoder". As
a consequence, the limit provided by SDI (Safe Direction) from r9733 no longer functions.
Notice:
An
appropriate fault is output for a drive data set changeover where the direction of rotation changes and the
pulses are enabled.
Note:
For operation with
the phase sequence U/V/W, the direction of rotation is defined when viewing the face side
of the motor output shaft.
When changing the direction of rotation, the rotating field direction of the current controller is reversed. The
speed actual value (e.g. r0063) is also reversed so that the control sense is kept and internally causing the
direction of rotation to be reversed with the same setpoint. Further, the position actual values of the actual
encoder are reversed (e.g. r0482[0...2]).
p29000 Motor ID 0 54251 [0] 0 - U16 IM T
Description:
Motor type number is printed on the motor rating plate as motor ID.
For
a motor
with an incremental encoder, users need to manually input the parameter value, ranging from 18
to 39. For a motor with an absolute encoder, the drive automatically reads the parameter value, ranging from
10009 to 10048.
Dependency: -
r3998[0...n] First drive commissioning 0 65535 - - U16 IM -
Description:
Displays whether the drive still has to be commissioned for the first time.
0 = Yes
2 = No
Dependency: -
7.2 SINAMICS V60 parameters
Editable parameters
Par. No. Name Range Default Increment Unit Effective
P01 Parameter write protection 0 - 1 0 1 - Immediately
0: Sets all parameters other than P01 as read-only parameters.
1: Sets all parameters to be both readable and writable.
P01 automatically resets to 0 after power-on.
SINAMICS parameters
7.2 SINAMICS V60 parameters
Parameter Manual
520 List Manual, 01/2017
