Siemens SINUMERIK 808D Parameter Manual

Data class Write rights Access right
I (Individual)
Note:
Individual machine data are grouped in this data class,
e.g. the leadscrew error compensation values.
Depending on the contents, these are accessible via dif‐
ferent access levels.
Manufacturer
or
Customer
Access levels 1 (password: SUNRISE)
or
Access level 3 (password: CUSTOMER)
U (User) Customer Access level 3 (password: CUSTOMER)
Access levels 4 to 6 (key-operated switch)
1)
1)
Access rights for
protection levels 4 to 6 are only suggestions and can be altered by the machine tool manufacturer or end
user.
2.2 Overview of the data
Machine and setting data (SINUMERIK)
The machine and setting data are divided into the following areas:
Range Designation
from 200 to 9999 Display machine data
from 10000 to 18999 General NC machine data
from 19000 to 19999 Reserved
from 20000 to 28999 Channel-specific machine data
from 29000 to 29999 Reserved
from 30000 to 38999 Axis-specific machine data
from 39000 to 39999 Reserved
from 41000 to 41999 General setting data
from 42000 to 42999 Channel-specific setting data
from 43000 to 43999 Axis-specific setting data
Data identifiers
The identifier specified
in the data description is displayed on the HMI user interface; however,
if the data is addressed in the parts program, for example, the identifier of the relevant data
area must precede the data identifier (designator).
Identifier Data area
$MM_ Display machine data
$MN_/ $SN_
$MNS_/ $SNS_
General machine/setting data
Explanation of machine data and setting data
2.2 Overview of the data
Parameter Manual
18 List Manual, 01/2017
