Means that an AXCTSWE fetches all the axis container axes that can be assigned to the
channel by means of implicit GET or GETD, and an axis replacement is not permitted
again until after the axis container rotation.
Bit2 = 1
Means that, in the case of a GET, an intermediate block without preprocessing stop is
generated, and whether a reorganization is needed is not checked until main run.
Bit3 = 1 means, that the NC carries out an axis replacement request for the VDI
interface only for:
- an axis exclusively controlled by the PLC (MD30460 $MA_BASE_FUNCTION_MASK
Bit 4 == 1)
- a permanently assigned PLC axis (MD30460 $MA_BASE_FUNCTION_MASK Bit 5 == 1)
For such axes, the VDI interface signal 'Axis replacement possible' is always
1.
For all other axes, the VDI interface signal 'Axis replacement possible' is
always 0.
For permanently assigned PLC axes, an axis replacement is possible only from
neutral axis to PLC axis
or from PLC axis to neutral axis.
Bit3 = 0 means that an axis replacement can be requested by the PLC for each axis.
For permanently assigned PLC axes, an axis replacement is only possible from
neutral axis to PLC axis
or from PLC axis to neutral axis.
10724 NC_SYS_CODE_CONF_NAME_TAB EXP, N01 TE1, B1
- List of internal NC codes STRING PowerOn
-
- 20 - - - ReadOnly S
Description: Identifier list of internal NC codes
Reserved for internal applications
10735 JOG_MODE_MASK EXP, N01 K1
- Settings for JOG mode DWORD PowerOn
-
- - 0 0 0x1ff 2/2 M
Description: Bit 0:
Enables JOG in automatic.
JOG is enabled in automatic when all channels in the mode group are in the RESET state
and no channel of the DRF mode group has been selected. The mode group changes
internally to JOG with the +/- key and the handwheel, and the axis moves. After the
JOG motion has ended, a change back to AUTO is also made internally.
Bit 1:
Position with AxFrame.
The function 'JOG to position' considers all axial frames and, in the case of an axis
configured as geometry axis, the tool length offset.
Bit 2:
Travel in opposite direction.
The functions 'JOG to position' and 'Approach machine fixed point manually' allow
travel in opposite direction, i.e. away from the specified position.
Bit 3:
Tool radius offset.
MD21020 $MC_WORKAREA_WITH_TOOL_RADIUS is active with JOG motions of the geometry axes.
Bit 4:
Machine data
3.2 General machine data
Parameter Manual
50 List Manual, 01/2017
