1 ;SEGMENT_840D_HW
1 ;SEGMENT_8xxD_HW; 828D sl, 808D -HW
1..6 ;SEGMENT_PROFIBUS/PROFINET ;index for MD11353
$MN_HANDWHEEL_LOGIC_ADDRESS[(x-1)]
1 ;SEGMENT_ETHERNET
11352 HANDWHEEL_INPUT N09 H1
- Handwheel connection BYTE PowerOn
-
808d-me42 6 1, 2, 0, 0, 0, 0 0 6 ReadOnly M
808d-me62 6 1, 2, 0, 0, 0, 0 0 6 ReadOnly M
808d-te42 6 1, 2, 0, 0, 0, 0 0 6 ReadOnly M
808d-te62 6 1, 2, 0, 0, 0, 0 0 6 ReadOnly M
808d-mte40 6 1, 2, 0, 0, 0, 0 0 6 7/2 M
808d-mte60 6 1, 2, 0, 0, 0, 0 0 6 7/2 M
Description: Machine data which is intended to select
the handwheels connected to
a hardware module:
0 = No handwheel configured
1..6 = Handwheel connection to HW module/Ethernet interface
11353 HANDWHEEL_LOGIC_ADDRESS N04, N10 H1
- Logical handwheel slot addresses DWORD PowerOn
-
808d-me42 6 0, 0, 0, 0, 0, 0 0 16383 ReadOnly M
808d-me62 6 0, 0, 0, 0, 0, 0 0 16383 ReadOnly M
808d-te42 6 0, 0, 0, 0, 0, 0 0 16383 ReadOnly M
808d-te62 6 0, 0, 0, 0, 0, 0 0 16383 ReadOnly M
808d-mte40 6 0, 0, 0, 0, 0, 0 0 16383 7/2 M
808d-mte60 6 0, 0, 0, 0, 0, 0 0 16383 7/2 M
Description: For PROFIBUS/PROFINET only:
Logical start address of the hand wheel slots if handwheels are connected by PROFIBUS/
PROFINET (MD11340 $MN_HANDWHEEL_SEGMENT = 5)
11354 HANDWHEEL_FILTER_TIME N09 -
s Filter time for handwheel pulses DOUBLE PowerOn
-
808d-me42 6 0.0, 0.0, 0.0, 0.0, 0.0,
0.0
0.0 2.0 ReadOnly M
808d-me62 6 0.0, 0.0, 0.0, 0.0, 0.0,
0.0
0.0 2.0 ReadOnly M
808d-te42 6 0.0, 0.0, 0.0, 0.0, 0.0,
0.0
0.0 2.0 ReadOnly M
808d-te62 6 0.0, 0.0, 0.0, 0.0, 0.0,
0.0
0.0 2.0 ReadOnly M
808d-mte40 6 0.0, 0.0, 0.0, 0.0, 0.0,
0.0
0.0 2.0 7/2 M
808d-mte60 6 0.0, 0.0, 0.0, 0.0, 0.0,
0.0
0.0 2.0 7/2 M
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 71
