SD43790 $SA_OSCILL_START_POS
10710 PROG_SD_RESET_SAVE_TAB EXP, N01 A3, V1
- Setting data to be updated DWORD PowerOn
-
- 30 0, 0, 0, 0, 0, 0, 0, 0... - - 2/2 M
Description: Setting data to be backed up
The values of the SDs listed in this table are stored in non-volatile memory, i.e. they
remain valid after power ON. The setting data whose HMI numbers were entered in the
backup list are written into the (buffered) active file system after the description
of the part program on reset.
Programmable setting data are:
(GCODE)
SD 42000 $SC_THREAD_START_ANGLE SF
SD 42010: $SC_THREAD_RAMP_DISP DITS/DITE
SD 42400 $SC_PUNCH_DWELLTIME PDELAYON
SD 42800 $SC_SPIND_ASSIGN_TAB SETMS
SD 43200: $SA_SPIND_S S with G94,G95,G97,G971,G972
SD 43202: $SA_SPIND_CONSTCUT_S S with G96,G961,G962
SD 43210 $SA_SPIND_MIN_VELO_G25 G25S
SD 43220 $SA_SPIND_MAX_VELO_G26 G26 S
SD 43230 $SA_SPIND_MAX_VELO_LIMS LIMS
SD 43300 $SA_ASSIGN_FEED_PER_REV_SOURCE FPRAON
SD 43420 $SA_WORKAREA_LIMIT_PLUS G26
SD 43430 $SA_WORKAREA_LIMIT_MINUS G25
SD 43700 $SA_OSCILL_REVERSE_POS1 OSP1
SD 43710 $SA_OSCILL_REVERSE_POS2 OSP2
SD 43720 $SA_OSCILL_DWELL_TIME1 OST1
SD 43730 $SA_OSCILL_DWELL_TIME2 OST2
SD 43740 $SA_OSCILL_VELO FA
SD 43750 $SA_OSCILL_NUM_SPARK_CYCLES OSNSC
SD 43760 $SA_OSCILL_END_POS OSE
SD 43770 $SA_OSCILL_CTRL_MASK OSCTRL
SD 43780 $SA_OSCILL_IS_ACTIVE OS
The values of D43420 $SA_WORKAREA_LIMIT_PLUS (working area limitation plus) and
SD43430 $SA_WORKAREA_LIMIT_MINUS (working area limitation minus) are to be stored in
the buffered RAM after every RESET, M02, M30 or M17.
--> PROG_SD_RESET_SAVE_TAB[0] = 43420
--> PROG_SD_RESET_SAVE_TAB[1] = 43430
See also: 'REDEF: change attributes of NC language elements', setting data/PRLOC
10712 NC_USER_CODE_CONF_NAME_TAB EXP, N01, N12 TE1, B1
- List of reconfigured NC codes STRING PowerOn
-
- 22 G58, G59, G505, G58,
G506, G59, WAITM,
WAITM
- - 2/2 M
Description: List of identifiers of the NC codes reconfigured by the user.
The list is to be structured as follows:
Even address: Identifier to be changed
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 45
