Note
The axis actual values and distances-to-go can be separately requested:
● DB2600.DBX0001.1 Request axis actual values
● DB2600.DBX0001.2 Request axis distances-to-go
If the particular request is set, then the NCK supplies these values for all axes.
6.15 Maintenance scheduler: User interface
6.15.1 Initial (start) data
DB9903 Initial data table [r16]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Interval 1 [h]
2 Time of first warning 1 [h]
4 Number of warnings to be output 1
6 Reserved 1
8 Interval 2 [h]
10 Time of first warning 2 [h]
11 Number of warnings to be output 2
14 Reserved 2
... ...
248 Interval 32 [h]
250 Time of first warning 32 [h]
252 Number of warnings to be output 32
254 Reserved 32
6.15.2 Actual data
DB9904 Actual data table [r16]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Interval 1 [h]
2 Number of warnings to be output 1
4 Reserved_1 1
6 Reserved_2 1
8 Interval 2 [h]
10 Number of warnings to be output 2
PLC user interface
6.15 Maintenance scheduler: User interface
Parameter Manual
List Manual, 01/2017 505
