Execution of the replacement subprogram at end of block (default value)
Bit 1 = 1
Execution of the replacement subprogram at block start
Bit 2 = 0:
Execution of the replacement subprogram according to the settin of bit 1
Bit 2 = 1:
Execution of the replacement subprogram at block start and at end of block.
10720 OPERATING_MODE_DEFAULT N01 H2
- Setting of mode after power ON BYTE PowerOn
-
- 1 7, 7, 7, 7, 7, 7, 7, 7... 0 12 1/1 M
Description: Default modes of the mode groups after power ON.
If no mode is selected by the PLC, all the channels associated with mode group n are
in the mode preset by OPERATING_MODE_DEFAULT[ n -1 ] after power ON:
0 = Automatic mode
1 = Automatic mode, submode REPOS
2 = MDI mode
3 = MDI mode, submode REPOS
5 = MDI mode, submode Reference point approach
6 = JOG mode
7 = JOG mode, submode Reference point approach
NOTICE! Depending on the machine data MD10721 $MN_OPERATING_MODE_EXTENDED, the mode
set here might not be adopted after power ON
10721 OPERATING_MODE_EXTENDED N01 H2
- Extended setting of mode after power ON BYTE PowerOn
-
- 1 0, 0, 0, 0, 0, 0, 0, 0... 0 1 1/1 M
Description: Extended setting of an operating mode of the operating mode groups after power on:
0 = Selection of the operating mode according to MD10720 $MN_OPERATING_MODE_DEFAULT
1 = Selection of the JOG mode if the PLC signal "Retract data available"
(DB3300.DBX4005.5) is set in at least one channel of the operating mode group
10722 AXCHANGE_MASK EXP, N01 K5
- Parameterization for axis replacement behavior DWORD PowerOn
-
808d-me42 - 0 0 0xFFFF 0/0 S
808d-me62 - 0 0 0xFFFF 0/0 S
808d-te42 - 0 0 0xFFFF 0/0 S
808d-te62 - 0 0 0xFFFF 0/0 S
808d-mte40 - 0 0 0xFFFF 7/2 M
808d-mte60 - 0 0 0xFFFF 7/2 M
Description: The axis replacement behavior can be changed with this
machine data.
Bit0 = 1
Means that there is an automatic axis replacement via channels even if the axis has
been brought into a neutral state by Waitp.
Bit1 = 1
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 49
