6 When the bit is set, neutral axes and positioning spindles are repositioned after
SERUPRO as command axes in the approach block.
7 The bit changes the behavior of the VDI-AXIN interface signal "Repos Delay". The
level of "Repos
Delay" is read if REPOSA is interpreted. Axes that are neither geo nor
orientation axes are then excluded from the REPOS, that is REPOS does NOT move these
axes. NOTICE: This bit completely switches off the channel-specific VDI Signal
ReposPathMode.
11510 IPO_MAX_LOAD N01, N05 -
% Max. permitted IPO load DOUBLE PowerOn
-
- - 0.00 0.0 100.0 1/1 M
Description: Enable utilization analysis via synchronized actions.
This MD11510 $MN_IPO_MAX_LOAD sets the IPO computing time (in % of the IPO cycle) after
which the variable $AN_IPO_LOAD_LIMIT is to be set to TRUE. The variable is reset to
FALSE if the value falls below this after having once exceeded it.
This diagnostics function is disabled if the machine data is 0.
11550 STOP_MODE_MASK N01 V1
- Defines the stop behavior. DWORD PowerOn
-
- - 0 0 0x1 2/2 M
Description: This MD describes the stop behavior of the NCK under certain conditions:
Bit no. Meaning
Bit 0 == 0 :=
No stop if G codes G331/G332 are active and a path motion or G4 has also been
programmed.
Bit 0 == 1 :=
A stop is possible during G331/G332 with interruption of the continuous-path mode (G60
or G4 between G331/G332 blocks interrupt the continuous-path mode).
Bits 1.....15
Not assigned
11602 ASUP_START_MASK N01 K1, M3, TE3, TE7
- Ignore stop conditions for ASUB DWORD PowerOn
-
808d-me42 - 0x01 0 0xf 1/1 M
808d-me62 - 0x01 0 0xf 1/1 M
808d-te42 - 0x01 0 0xf 1/1 M
808d-te62 - 0x01 0 0xf 1/1 M
808d-mte40 - 0 0 0xf 2/2 M
808d-mte60 - 0 0 0xf 2/2 M
Description: This machine data defines which stop reasons are to be ignored on an ASUB start. The
ASUB is started or the following stop reasons are ignored:
Bit 0:
STOP reason: STOP key, M0 or M01
An ASUB is started immediately if NCK is in RESET status (or JOG mode) (no ASUB can be
started in RESET/JOG without this bit).
Bit 1:
Reserved! This bit was replaced by MD20105 $MC_PROG_EVENT_IGN_REFP_LOCK and MD20115
$MC_IGNORE_REFP_LOCK_ASUP.
Machine data
3.2 General machine data
Parameter Manual
74 List Manual, 01/2017
