Machine data
3
You can call the help information for the machine data on the PPU by proceeding through the
following steps:
+ 1. Select the system data operating area.
2. Press this softkey to open the machine data window.
3. Open the target data list and select the desired data using the cursor
keys.
4. Press this key to call the help information for the selected data.
Note:
You can further press this softkey in the current help screen to
show a complete list of all SINUMERIK 808D/SINUMERIK 808D AD‐
VANCED machine data. In addition, you can also use the following
softkey to search for a specific MD by number in this list:
5. Pressing this softkey exits the help system.
3.1 Display machine data
1091 SINAMICS_IBN_TIMEOUT_VALUE - -
- Wait time when reading in parameters for Sinamics commissioning DWORD Immediately
-
- - 230 0 1000 3/3 U
Description: Defines the wait time on read-in of the parameters for all SINAMICS devices during
commissioning
1092 MAX_SPINDEL_SPEED_MANUAL_MA - -
- Input limit spindle speed MM+ DOUBLE Immediately
-
- - 99999.00000 0 99999.00000 2/2 M
Description: Input limit spindle speed MM+
1093 MAX_SPEED_G96_MANUAL_MA - -
- Input limit cutting meter MM+ DOUBLE Immediately
-
- - 99999.00000 0 99999.00000 2/2 M
Parameter Manual
List Manual, 01/2017 21
