Siemens SINUMERIK 808D Parameter Manual

11100 AUXFU_MAXNUM_GROUP_ASSIGN N01, N07, N02 H2
- Number of auxiliary functions distr. amongst aux. fct. groups DWORD PowerOn
-
- - 1 1 255 2/2 M
Description: The maximum number of auxiliary functions that can be assigned to a group by
AUXFU_ASSIGN_TYPE,
AUXFU_ASSIGN_EXTENTION,
AUXFU_ASSIGN_VALUE and
AUXFU_ASSIGN_GROUP.
This number includes only the user-defined auxiliary functions, not the predefined
auxiliary functions.
Related to:
MD22010 $MC_AUXFU_ASSIGN_TYPE[n].
11110 AUXFU_GROUP_SPEC N07 H2
- Auxiliary function group specification DWORD PowerOn
-
808d-me42 168 0x8081, 0x8021,
0x8041, 0x8041,
0x8041, 0x8041,
0x8041, 0x8041...
0 0x7FFFFFFF 1/1 M
808d-me62 168 0x8081, 0x8021,
0x8041, 0x8041,
0x8041, 0x8041,
0x8041, 0x8041...
0 0x7FFFFFFF 1/1 M
808d-te42 168 0x8081, 0x8021,
0x8041, 0x8041,
0x8041, 0x8041,
0x8041, 0x8041...
0 0x7FFFFFFF 1/1 M
808d-te62 168 0x8081, 0x8021,
0x8041, 0x8041,
0x8041, 0x8041,
0x8041, 0x8041...
0 0x7FFFFFFF 1/1 M
808d-mte40 168 0x81, 0x21, 0x41,
0x41, 0x41, 0x41,
0x41, 0x41...
0 0x7FFFFFFF 1/1 M
808d-mte60 168 0x81, 0x21, 0x41,
0x41, 0x41, 0x41,
0x41, 0x41...
0 0x7FFFFFFF 1/1 M
Description: Defines the output options for the auxiliary functions belonging to a group.
However, the output option of an auxiliary function configured by MD22080
$MC_AUXFU_PREDEF_SPEC[ preIndex ] or MD22035 $MC_AUXFU_ASSIGN_SPEC[ auxIndex ] has a
higher priority.
Bit 0=1 "Normal" acknowledgment after an OB1 cycle
Bit 1=1 "Quick" acknowledgment with OB40
Bit 2=1 No predefined auxiliary function
Bit 3=1 No output to PLC
Bit 4=1 Spindle response after acknowledgment by the PLC
Bit 5=1 Output prior to motion
Bit 6=1 Output during motion
Bit 7=1 Output at end of block
Bit 8=1 No output after block search types 1, 2, 4
Machine data
3.2 General machine data
Parameter Manual
60 List Manual, 01/2017
