Using M96/M97 to activate an interrupt program is allowed
Bit 1 = 0,
Continue processing part program at the final position of the next block after the
interrupt block
Bit 1 = 1,
Continue processing part program from interrupt position
Bit 2 = 0,
The interrupt signal immediately interrupts the current block and starts the interrupt
routine
Bit 2 = 1,
The interrupt routine will not be started until the end of the block
Bit 3 = 0,
Interrupt machining cycle at an interupt signal
Bit 3 = 1,
Do not start interrupt program until the end of a machining cycle.
10810 EXTERN_MEAS_G31_P_SIGNAL EXP, N12 FBFA
- Config. of measuring inputs for G31 P.. BYTE PowerOn
-
- 4 1, 1, 1, 1 0 0x3 2/2 M
Description: This machine data defines the assignment of measurement inputs 1 and 2 to the P numbers
programmed with G31 P1 ( - P4). The machine data is bit-coded. Only bits 0 and 1 are
evaluated. For example, if bit 0 = 1 in MD10810 $MN_EXTERN_MEAS_G31_P_SIGNAL[1], the
1st measurement input is activated with G31 P2. If MD10810
$MN_EXTERN_MEAS_G31_P_SIGNAL[3]=2, the 2nd
measurement input is activated with G31 P4.
Bit 0: = 0, Do not evaluate measurement input 1 with G31 P1 (- P4)
Bit 0: = 1, Activate measurement input 1 with G31 P1 (- P4)
Bit 1: = 0, Do not evaluate measurement input 2 with G31 P1 (- P4)
Bit 1: = 1, Activate measurement input 2 with G31 P1 (- P4)
10814 EXTERN_M_NO_MAC_CYCLE EXP, N12 H2, K1
- Macro call via M function DWORD PowerOn
-
- 30 -1, -1, -1, -1, -1, -1, -1,
-1...
- - 2/2 M
Description: A macro is called with this M number.
The name of the subprogram is stated in MD10815 $MN_EXTERN_M_NO_MAC_CYCLE_NAME[n].
If the M function specified with MD10814 $MN_EXTERN_M_NO_MAC_CYCLE[n] is programmed in
a part program block, the subprogram defined in MD10815
$MN_EXTERN_M_NO_MAC_CYCLE_NAME[n] is started. All addresses programmed in the block
are written into the corresponding variables.
If the M function is programmed again in the subprogram, there is no longer a
replacement by a subprogram call.
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE[n] is only active in the external language mode G291.
The subprograms configured with MD10815 $MN_EXTERN_M_NO_MAC_CYCLE_NAME[n] must not be
active simultaneously in a block (part program line), i.e. only one M function
replacement
can become
active in any one block. Neither an M98 nor a modal subprogram
call may be programmed in the block with the M function replacement.
Subprogram return and the part program end are also not permitted. Alarm 14016 is
issued in case of a conflict. Restrictions: see MD10715 $MN_M_NO_FCT_CYCLE
Related to:
MD10714 $MN_M_NO_FCT_EOP,
Machine data
3.2 General machine data
Parameter Manual
52 List Manual, 01/2017
