Description: This MD is used to define the number of decimal places of the position display for
linear axes in the inch system of measurement.
The position display is displayed with a max. of 10 characters including signs and
decimal places. A positive sign is not displayed.
By default 4 digits are displayed after the decimal point.
MD value=4: display resolution = 10-4 [inch]
For rotary axes and spindle positions the display is maintained as in MD 203.
Related to:
MD 10200: INT_INCR_PER_MM, MD 203: DISPLAY_RESOLUTION
205 DISPLAY_RESOLUTION_SPINDLE - -
- Display resolution for spindle values BYTE Immediately
-
- 0 1 0 5 3/2 M
Description: This MD is used to define the number of decimal places for spindle speed display.
The values are displayed with a max. of 10 characters including sign and decimal point.
A positive sign is not displayed.
By default 1 digit is displayed after the decimal point.
MD value=1: display resolution = 10-1
207 USER_CLASS_READ_TOA - -
- Read tool offsets protection level, general BYTE Immediately
-
- 0 7 0 7 3/3 U
Description: Protection level of the tool offsets, general
208 USER_CLASS_WRITE_TOA_GEO - -
- Write tool geometry protection level BYTE Immediately
-
- 0 7 0 7 3/3 U
Description: Protection level for tool offsets (geometry) for writing
209 USER_CLASS_WRITE_TOA_WEAR - -
- Write tool wear data protection level BYTE Immediately
-
- 0 7 0 7 3/3 U
Description: Protection level of tool offsets (wear) for writing
210 USER_CLASS_WRITE_ZOA - -
- Write settable work offset protection level BYTE Immediately
-
- 0 7 0 7 3/3 U
Description: Protection level Settable work offset for writing
212 USER_CLASS_WRITE_SEA - -
- Protection level write setting data BYTE Immediately
-
- 0 7 0 7 3/3 U
Description: Protection level Setting data for writing
Machine data
3.1 Display machine data
Parameter Manual
List Manual, 01/2017 25
