Description: Input limit cutting meter MM+
1094 MAX_FEEDRATE_G94_MANUAL_MA - -
- Input limit time feed MM+ DOUBLE Immediately
-
- - 99999.00000 0 99999.00000 2/2 M
Description: Input limit time feed MM+
1095 MAX_FEEDRATE_G95_MANUAL_MA - -
- Input limit rotation feed MM+ DOUBLE Immediately
-
- - 99999.00000 0 99999.00000 2/2 M
Description: Input limit rotation feed MM+
1096 MAX_NUM_CYCLE_MANUAL_MA - -
- Number of managed masks per cycle in manual mode of MM+ DWORD Immediately
-
- - 9 1 9 3/3 U
Description: Number of managed masks per cycle in manual mode of MM+
1097 MAX_NUM_CUTT_EDGES_MANUAL_MA - -
- Number of managed cutting edges in MM+ DWORD Immediately
-
- - 9 1 9 3/3 U
Description: Number of managed cutting edges in MM+
1098 INVERT_SPIN_ICON_MANUAL_MA - -
- The direction of spindle rotation is displayed inverted. BOOLEAN Immediately
-
- - 1 0 1 3/2 M
Description: The direction of spindle rotation is displayed inverted.
1099 USE_FIXPOINT_MANUAL_MA - -
- Tool change step MM+ BOOLEAN Immediately
-
- - 1 0 1 3/3 U
Description: Tool change increment MM+:
The selection field for fixed-point approach is selected or deselected by default
1100 MEAS_SPIN_ACTIV_MANUAL_MA - -
- Measuring the tool offset data in the X direction with the spindle
rotating
BOOLEAN Immediately
-
- - 1 0 1 3/2 M
Description: If the value is 1, the tool offset data can be measured in the X direction with
rotating spindle.
Machine data
3.1 Display machine data
Parameter Manual
22 List Manual, 01/2017
